Beschreibung
The EOTech EXPS3-0 is a compact holographic sight, developed and manufactured by EOTech. The CNC-machined aluminium housing with matte black anodising provides high durability in a compact form factor. With a weight of 317 g and dimensions of 95 × 58 × 73 mm, it ranks among the compact devices in its class. The sealed construction makes the sight water-, dust- and fog-resistant as well as shockproof.
The 30 × 23 mm objective lens features an anti-scratch and anti-reflective coating. The reticle consists of a 1 MOA dot combined with a 68 MOA ring and a 1/2 MOA adjustment value. Projection is achieved via an integrated laser emitter with 20 brightness levels and 10 night vision modes. This configuration forms a reticle with a shotgun pattern. Parallax-free and with unlimited eye relief, the EXPS3-0 enables fast and precise target acquisition in all weather and lighting conditions – including at greater distances.
Power is supplied by one CR123A battery in a cap-secured battery compartment, providing a battery life of up to 1'000 hours at medium brightness. The Picatinny interface with QD mount ensures a stable and repeatable point of impact even under demanding conditions. Side-mounted, rubberised controls allow comfortable operation, even with a magnifier attached.
Technical specifications
Design: Holographic sight
Reticle: 68 MOA ring with 1 MOA dot
Adjustment: 1/2 MOA
Brightness levels: 20 daylight / 10 NV
Magnification: 1×
Eye relief: Unlimited
Parallax: Parallax-free
Objective size: 30 × 23 mm
Mount: Picatinny rail with QD
NV-compatible: Yes
Power supply: 1 × CR123A
Battery life: up to 1'000 h
Dimensions: 95 × 58 × 73 mm
Weight: 317 g
Scope of delivery
EOTech EXPS3-0
CR123A battery
User manual
Packaging data
Packaging dimensions: 18.6 × 16.6 × 9 cm
Packaging weight: 0.615 kg
The EOTech EXPS3-0 combines compact design, NV compatibility and proven holographic technology – a reliable optic for demanding applications and use with a magnifier.
